PEROLO DN50 ATCO BALL VALVE
PEROLO DN50 ATCO BALL VALVE

Our Price: $752.33


Product Code: BVFFD50-SS-01
Qty:

Description Technical Specs Sheet Information

MPN: AFN5X16T1300S00
ATCO™ 2” flanged ball valves are designed for use on tank containers, road tankers, rail tank cars and static tanks to be used for liquid transfer operation or as an airline.
Features
• 316L stainless steel construction
• PTFE and TFM gaskets and FEP/Silicone O’rings
• Comply with ADR, IMDG and EN 14 432
• Compact design. Face to face 81mm
• Light weight: 6kg
• Working pressure: 16 bar
• Test pressure: 24 bar
• Design temperature: - 40°C +190°C
• Easy maintenance
• Controlled tightening of the ball PTFE seal assembly
• Single seal design on both sides of the ball
• Compatible with standard interface for pneumatic actuator
• Pressure gauge connection
• Sealing
• HALAR® coating option available.

• Steam heating system option available.
