PEROLO DN80 ATCO BALL VALVE
PEROLO DN80 ATCO BALL VALVE

Our Price: $1,162.34


Product Code: BVFFD80-BF64-SS-01
Qty:

Description Technical Specs Sheet Information

MPN: AFN8X16T53S000
DN80 ATCO™ flanged full bore ball valves are designed for use on tank containers, road tankers, rail tank cars and static tanks to be used as an airline or for liquid transfer operation.
Features
• 316L stainless steel construction
• PTFE and TFM gaskets and FEP/Silicone O’rings
• Compact design, Face to face : 117mm
• Weight: 12.5kg
• Comply with EN 14432, ADR & IMDG
• Easy maintenance
• Controlled tightening of the ball PTFE seal assembly
• Compatible with standard interface for pneumatic actuator
• Working pressure: 16 bar
• Test pressure: 24 bar
• Design temperature: +190°C
• Pressure gauge connection available
• Sealing available
• HALAR® coating option available.
• Steam heating system option available.
• IMDG/ADR §6.7 conformity
