PEROLO 3" TANKFLY FLANGED B-FLY VALVE - 4 & 6 HOLE INLET FLANGE - SPLINED SHAFT
PEROLO 3" TANKFLY FLANGED B-FLY VALVE - 4 & 6 HOLE INLET FLANGE - SPLINED SHAFT

Our Price: $875.00


Product Code: BFFL300-BF64-SS-01C
Qty:

Description Sheet Information

TFS8X7T1100 (CURRENT)
MPN 1112310000D (discontinued)

The TANKFLY™ 3” flanged butterfly valve has 6 x 14 mm drillings on a 168 mm PCD and 4 x 18 mm drillings on a 160 mm PCD on the inlet flange, and 4 x slots 18 mm on a 146 mm PCD on the outlet flange.
Features
  • Weight 7.0 Kg
  • Inlet flange 6 x Ø14 x 168 PCD / 4 x Ø18 x 160 PCD
  • Outlet flange 4 slots x Ø18 on a 146 PCD*
  • Working Pressure 7 Bar
  • Test Pressure 10.5 Bar
  • Working Temperature STD:-40° to +150°C/ HT°:-20° to 250°C
  • Design Temperature STD:-40° to +250°C/ HT°:-20° to 250°C
  • Made of (material) - 316 / 1.4408 stainless steel
  • Compact Design - Face to face 54mm
  • Operation Handle - 1/4 turn with Locking
  • Closure plate seal - PTFE
