PEROLO 3" 45° NEATFLOW FOOT VALVE MK4
PEROLO 3" 45° NEATFLOW FOOT VALVE MK4



Our Price: $1,513.54


Product Code: FVNF300D-45D-SS-01
Qty:

Description Sheet Information

MPN NX34AX1

The new Perolo 3'' NEATFLOW™ MKIV external spring footvalve is designed to be used as a bottom discharge for chemicals and liquid foodstuff products carried in tank containers and IBC’s.
The external spring design is perfectly suited to tanks containing viscous fluids and allows easy cleaning and maintenance.
Features
• Nominal diameter : 84mm (3'')
• Weight:
• Container flange angled at 45°
• Container flange : 8 x d14 on a PCD178
• Outlet flange : 4 x d18 on a PCD160
• Working pressure: 4 bar
• Test pressure: 6 bar
• Working temperature: -40°C to 190°C
• Full 316L stainless steel construction
• FEP/Silicone O'rings
• PTFE Gaskets
• Footvalve spring outside the tank allows easier cleaning
• Valve maintainable when fitted on tank
• Improved discharge times
• Shear groove breaking system
• Double tightness on spindle
• Compact design

Options
• Bolted or welded Heating box
• M16 tapping on outlet flange
• Round outlet flange
• Remote control lever
• Conical poppet for congealing cargoes
• High Working Temperature (-40°C to 250°C)
• Pneumatic operating
• Alloy 20 construction
